Inverter hibrida 4200W 6200W, dengan pengontrol MPPT bawaan

Name: Inverter hibrida 4200W 6200W, dengan pengontrol MPPT bawaan
Brand: Guangzhou Anern Energy Technology Co., Ltd

Inverter hybrid seri AN-SCI-EVO-4200 & 6200 adalah inverter off-grid multi-fungsi yang ditingkatkan untuk menawarkan dukungan daya tanpa hambatan dalam ukuran portabel. Dengan output AC ganda yang baru ditambahkan dan kontroler Tenaga surya MPPT bawaan, inverter surya 4200w 6200w ini cocok untuk penggunaan perumahan dan cahaya komersial.

Dapatkan penawaran gratis

Unduh PDF

Video

Detail Inverter Hybrid 4200W 6200W dengan pengontrol MPPT bawaan

Kompatibel untuk aplikasi off-grid dan on-grid, dapat memberikan surplus tenaga surya ke dalam grid.

Aktivasi otomatis baterai litium bawaan, dapat mengaktifkan baterai litium aktif dengan mengisi daya.

Ini dapat digunakan sendiri untuk memasok beban dengan panel surya atau listrik kota, dan biasanya dapat digunakan tanpa baterai.

Fungsi pemantauan WIFI opsional, Anda dapat memeriksa status berjalan dari hybrid inverter untuk sistem surya melalui aplikasi kapan saja, dan menyadari operasi jarak jauh.

Key Features of 4.2kw 6.2kw Wholesale Mppt Solar Inverter:

Compatible for both off-grid & on-grid applications, able to feed surplus solar power into the grid;
Be able to run without battery;
One-key restoring to factory default settings;
Built-in Lithium battery automatic activation;
Built-in MPPT solar controller, max charge current 120A;
Max 6200W & 6500W solar input power respectively;
Wide PV input voltage range (90-450VDC);
Built-in anti-dusk kit for harsh environments.
Smart battery charge design to maximize battery lifespan
Dual AC output;
WIFI available for IOS and Android systems.

Specification of 4200W 6200W Hybrid Inverter with inbuilt MPPT Controller

Model	SCI-EVO-4200	SCI-EVO-6200
RATED POWER	4200W	6200W
Maximum PV Input Power	6200W	6500W
GRID-TIED OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage	360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage	90VDC/120VDC
MPPT DC Voltage Range	90-450VDC
Number of MPPT Trackers/Maximum Input Current	1/27A
GRID OUTPUT (AC)
Nominal AC Output Voltage	220/230/240VAC
AC Output Voltage Range	195.5-253VAC
Nominal AC Output Current	15.7A	27.0A
Power Factor	>0.99
Feed-in Grid Frequency Range	49-51±1Hz / 59-61±1Hz
EFFICIENCY
Maximum Conversion Efficiency (Solar to AC)	98%
TWO LOADS OUTPUT POWER
Full Load	4200W	6200W
Maximum Main Load	4200W	6200W
Maximum Second Load (battery mode)	1400W	2067W
Main Load Cut Off Voltage	22VDC	44VDC
Main Load Return Voltage	26VDC	52VDC
OFF-GRID OPERATION
AC Start-up Voltage/Auto Restart Voltage	120-140VAC/180VAC
Acceptable AC Input Voltage Range	90-280VAC or 170-280VAC
Maximum AC Input Current	30A	40A
Nominal Operating Frequency	50/60Hz
Surge Power	8400W	12400W
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	220/230/240VAC
Output Waveform	Pure sine wave
Efficiency (DC to AC)	94%
BATTERY & CHARGER
Nominal DC Voltage	24VDC	48VDC
Maximum Charging Current(Solar to AC)	120A
Maximum AC Charging Current	100A
GENERAL
Dimension, D x W x H (mm)	420350110mm	450350110mm
Net Weight (kgs)	9	10
Communication interface	WIFI
Humidity	5% to 95% Relative Humidity (Non-condensing)
Operating Temperature	–10°C - 50°C
Storage Temperature	–15°C - 60°C
